Light Load Drive Timing Belt Pulley T5/T10/T20 Type
The light load transmission timing belt pulley is suitable for trapezoidal tooth transmission. Made of aluminum, these pulleys have good corrosion resistance. The teeth match up with the grooves along the inside diameter of a timing belt to move components forward or backward. Select a pulley with a maximum belt width that’s the same or larger than your timing belt width. Pulleys without a shaft diameter have a pilot bore so that you can customize them to your needs.
Light Load Drive Timing Belt Pulley Overview
Light load drive timing belt pulleys are precision-engineered for low-torque, high-speed bi-directional transmission and delicate positioning applications. Machined primarily from high-strength 6061 aluminum alloy, these lightweight pulleys offer high strength-to-weight ratios, low rotational inertia, and excellent natural corrosion resistance. Specifically paired with trapezoidal (MXL, XL, L, T2.5, T5) and micro-pitch profiles (2GT, 3GT, S2M), they enable smooth, non-slip power motion in compact mechanical assemblies without imposing unnecessary shaft loads.
Product Specifications
| Parameter | Specification Detail |
|---|---|
| Product Name | Light Load Drive Pulley / Precision Micro Timing Pulley |
| Light Load Teeth Profiles | Classic Trapezoidal: MXL, XL, L, T2.5, T5, T10 Micro Precision GT Series: 2GT, 3GT, 5GT Small Pitch Curved Teeth: S2M, S3M, HTD 2M, HTD 3M, HTD 5M |
| Hub Configurations | Type A (Plain), Type B (Hubbed), Type D, Type E, Type F (Flanged), Type K |
| Teeth Range | 10 to 150 Teeth (Custom teeth counts available upon request) |
| Material Options | 6061-T6 Aluminum Alloy, POM/Nylon Plastic, SUS304 Stainless Steel, C45 Steel |
| Bore Configurations | Pilot Bore, Precision Finished Bore (H7), Keyway & Set Screws, D-Bore, Taper Hole |
| Belt Width Range | 4 mm to 50 mm |
| Surface Treatment | Clear Anodizing, Black Anodizing, Hard Anodizing, Electroless Nickel Plating, Phosphating |
| Quality Certification | ISO9001:2008 Standard |
| Quality Inspection | 2D Optical Projector, Surface Roughness Tester, Hardness Durometer, Salt Spray Tester |
Key Performance Advantages
- Low Rotational Inertia: Aluminum construction drastically reduces drive inertia, enabling instantaneous start-stop cycles and high acceleration rate.
- Zero Backlash Motion: Precision gear hobbing ensures exact mesh engagement with standard timing belts to eliminate position drift and angular backlash.
- Maintenance-Free & Quiet: Requires zero oil lubrication, ensuring clean operation for sensitive laboratory, optical, or textile working environments.
- Custom Bore Versatility: Available in pilot bore stock for local machining or finished H7 precision bore setups with set screws and keyways.
Target Application Industries
- 3C Electronics & Robotics: Automated pick-and-place heads, 3D printers, and optical inspection equipment.
- Medical & Pharmaceutical Devices: Diagnostic scanners, fluid dosing pumps, and lab automation devices.
- Textile & Light Packaging Equipment: Yarn feeding drives, light conveyor indexing, and pouch sealing machinery.
- Food Processing & Office Automation: Bakery light feeders, ticketing dispensers, and printing machinery.
Why Partner With PowerTrans?
- 1-Year Quality Warranty: Full product compliance with international ISO9001 quality standards. Free replacement or maintenance guaranteed for non-conforming items within 1 year.
- Fast CAD Engineering Quotation: Send us your custom drawings for quick technical evaluation. Our engineering team can also generate 2D/3D CAD models based on your specifications.
- Low MOQ & Prototypes: Single-piece sample orders welcomed for functional prototype validation.
- Strict NDA Protection: Your OEM designs and technical files are fully protected under signed non-disclosure agreements.
